The DeepCool CH260 Wood is a micro-ATX mini tower PC case that combines a compact footprint with support for full-size components. Finished with a wood-grain I/O accent and a tempered glass side panel, it offers a natural aesthetic that blends into modern living spaces while showcasing your build. The full steel mesh panels deliver high airflow, making it suitable for performance-oriented systems.
Key Features
- Wood-grain I/O panel for a natural, furniture-like appearance.
- Tempered glass side panel to display internal components.
- Full steel mesh front and top panels for optimal airflow.
- Supports Mini-ITX, Micro-ATX, and Micro-ATX (Rear Connector) motherboards, with 29.6 mm backplane clearance for rear-connector boards.
- Fits graphics cards up to 388 mm (413 mm without front fans).
- ATX power supply support with a removable bracket for easier cable management.
- Fan placements for up to six 120 mm fans and radiator support up to 360 mm on top.
- No pre-installed fans, allowing fully custom cooling configurations.
Specifications
| Attribute | Value |
|---|---|
| Product Dimensions | 438 × 225 × 312.5 mm (L×W×H) |
| Net Weight | 5.3 kg |
| Materials | ABS, SPCC, Tempered Glass |
| Motherboard Support | Mini-ITX, Micro-ATX, Micro-ATX (Rear Connector) |
| Drive Bays | 3.5″ × 1, 2.5″ × 1 |
| Expansion Slots | 4 |
| CPU Cooler Height Limit | 174 mm |
| GPU Length Limit | 388 mm (413 mm without front fans) |
| Power Supply Type | ATX PS2 (max length 150 mm) |
| Fan Support | Front: 2×120mm; Top: 3×120mm / 2×140mm; Rear: 1×120mm |
| Radiator Support | Top: 120/140/240/280/360mm; Rear: 120mm |
| Pre-Installed Fans | None |
| Warranty | 1 Year Return To Base |
| EAN | 6933412765653 |
Front I/O Ports
- 2 × USB 3.0
- 1 × USB 3.2 Gen 2 Type-C
- 1 × Audio/Mic combo jack
